Accessories for Millenium 3

? Millenium power supply

■ With a switch mode power supply, regulated and

protected against overloads and short-circuits, these

new power supply units are easily integrated in

switchboards and enclosures.

■ The potentiometer can be used to set the output

voltage between 100 and 120% (24 V c versions) to

compensate for any voltage drops on the line.

■ The LED continuously signals the presence of voltage

at the output and, when flashing, triggering of the self-

protection.

■ Broad range of supply voltage 85 V ? 264 V a .

Part numbers

Type

Nominal output voltage

5 V c (4.75 V ? 6.25 V)

12 V c (11.4 V ? 15 V)

24 V c (22.8 V ? 28.8 V)

Nominal power

20 W

25 W

7.5 W

15 W

30 W

60 W

Nominal output current

2.1 A

0.3 A

0.6 A

1.2 A

2.5 A

Code

88950305

88950306

88950303

88950304

88950307

88950302

General characteristics

Environmental characteristics

Conformity to standards

Certifications

Operating temperature

Storage temperature

Electrical characteristics

Input voltage

Supply frequency range

Output voltage

Regulation of line and load

Immunity from micro power cuts

Technology

Short-circuit protection

Overload protection

Primary protection

Reset after overload

Status indication

Mechanical characteristics

Mounting

Screw terminals connection capacity

IEC/EN 60950-1

IEC/EN 61000-6-2

IEC/EN 61000-6-3

IEC/EN 61204-3

IEC/EN 55022 class B

IEC/EN 60364-4-41

cULus 508; cCSAus (CSA22.2 n950-1) ; TUV EN 60950-1; CE

-25 ? +55°C

-40 ? +70°C

100 ? 240 V a single-phase

50/60 Hz (+4% / -6%)

or 47 ? 53 Hz/57 ? 63 Hz

Adjustable from 100 ? 120%

± 3%

> 10 ms

Primary switch mode electronic power supplies

Yes

Fuse gG 2 A or circuit breaker 2A curve D for 88950303, 88950304,

88950305, 88950306, 88950307

Fuse gG 3 A or circuit breaker 3A curve D for 88950302

Automatic

LED at the output

On section, 35 x 7, 5 mm and 35 x 15 mm or on panel (2 x ?4 mm)

Input connection 2 x 0.14 < 2.5 mm 2 (AWG26...AWG14)

Output connection 1 x 0.14 < 2.5 mm 2 (AWG26...AWG14)

To order, see page 8
